Description
Features
500 Hour Oil Change (Select Models)
Vanguard™ Engines with Oil Guard System reduce maintenance time and costs by up to 60%.**
Patented Suspension
Consists of rear coil-over-shocks (shown) and pivoting front axle with coil-over-shocks.
Ride-On Mower Warranties†
Coil-Over-Shocks and all suspension-related components are covered for 5 years (60 months), for unlimited hours. We are committed to providing performance, productivity and durability.
Smooth Controls
Smooth, precision controls last longer as a result of pillow block bearings on control mounts.
Powerful Engine
For the most challenging applications, this Big Block engine has been expertly engineered to deliver the dependability to get more done in less time. Models are available with 32 or 37 Gross HP*.
Drive System
Dual, commercial Hydro-Gear ZT-4400 transaxles, with 8.3-inch cooling fans, deliver unmatched power and durability.
Easy Access
Quick removal of the floor pan provides convenient access to the top of the deck for easy cleaning and service.
Adjust Cut Height
Foot-operated deck lift, with adjustable pedal, can change cut height in 1/4" increments from 1.5"- 5".
Drive Tires
Large 26" drive tires allow for greater traction, smoother ride and improved curb climbing performance.
Hercules™ II Cast-Iron
Hercules™ II Cast-Iron; 10" dia. cast-iron with industrial double row angular contact ball bearing with 1 3/16" dia. shaft. Contact ball bearings with 1 3/16" dia. shaft.
Acres Per Hour
Mows up to 7.2 acres per hour, based on 80% efficiency.
Miles Per Hour
Up to 12 MPH ground speed, reverse 6 MPH.
* All power levels are stated gross horsepower at 3600 rpm per SAE J1940 as rated by Briggs & Stratton
** Cost savings based on oil maintenance with 100 hour interval versus Oil Guard System 500 hour service interval.
† See operator's manual or dealer for complete warranty details. Refer to engine operator's manual for engine warranty.
This is test Line for update product
Specifications
Engine BrandVanguard™ BIG BLOCK™ EFI with Oil GuardEngine Power Rating *37Displacement (cc)993PTOElectricCylinders2StarterElectricFuel Tank Capacity (gal)11Cutting Width (in)72Cutting Height (in)1.5 - 5SpindlesHercules™ II Cast-IronDeck ConstructioniCD™ Cutting SystemSuspensionAdjustable rear coil-over-shocks and front independent adjustable coil-over-shocksTransmissionDual Commercial Hydro-Gear® ZT-5400 Powertrain® transaxles with 9" cooling fansDrive Axles (in)1.375Caster Tires (in)13 X 6.5 - 6Drive Tires (in)26 X 12-12Ground Speed-Fwd (mph)0-12Ground Speed-Rev (mph)0-5Overall Length (in)84.5Overall Width (in) Deflector Down/Deflector Up85.75 / 76.5Dry Weight (lbs)1511Seat PackageSuspension SeatCertified Roll-over Protection SystemStandard, 165° foldableControls / Safety GroupSeat activated engine kill, clutch safety switch, neutral and parking brake safety circuit, adjustable twin steering controlsParking Brake / Safety CircuitInternal transaxles
